How Big Is a 140 × 200 Cross Stitch Pattern?
The 140 × 200 chart makes a portrait rectangle, measuring 10.00 × 14.29 inches (25.40 × 36.29 cm) on 14ct Aida. Its longer side is the useful first check when choosing a frame. A design can fit an opening while the bordered composition, mount or cloth cut needs more room.
A 140 × 200 cross-stitch pattern measures 10.00 × 14.29 inches (25.40 × 36.29 cm) on 14ct Aida. On 16ct it is 8.75 × 12.50 inches (22.23 × 31.75 cm), and on 18ct it is 7.78 × 11.11 inches (19.76 × 28.22 cm). These are stitched dimensions; the table adds an explicit 3-inch planning margin on every side.
Test the intended orientation before buying a frame
The 14ct stitched rectangle does not fit an 8 × 10 inch opening and does not fit an 11 × 14 inch opening. Turning it sideways cannot fix an opening whose dimensions still fail the rectangular fit check.
Write down the usable opening rather than the outside frame dimensions. Compare a portrait opening with the upright design, then swap the opening’s axes if you intend landscape display. The fit helper permits rotation; your picture’s subject may not.
Two decisions for this project
Opening example: 12 × 16 inches on 14ct
The 10.00 × 14.29 inch stitched image fits the measured opening without a separate border. Add 1.50 inches of visible fabric per side and the composition becomes 13.00 × 17.29 inches, which does not fit.
The table’s 16.00 × 20.29 inch cut already includes finishing cloth, but that cloth is not automatically display border. Specify both fields when you want the larger bordered composition.
Denser-fabric example: keep a border in an 11 × 14 opening
On 18ct, the design is 7.78 × 11.11 inches. An illustrative 1.00 inch border produces a 9.78 × 13.11 inch display rectangle, which fits the actual opening. Adding 3.00 inches per side for mounting yields a 15.78 × 19.11 inch nominal cut.
This checks rectangles only. A mat’s overlap, the desired visual balance and the chosen mounting method can require different dimensions; confirm those before trimming.
140 × 200: design, fabric cut and working opening
Measurements use nominal count, then convert unrounded inches with 1 in = 2.54 cm. Display rounds half-up to two decimal places. Every cut on this page adds only 3 in per side: visible border 0 + finishing allowance 3. The main calculator normally starts with a separate 1.5 in border plus 3 in finishing; the links here explicitly select this table’s 0 + 3 example. Actual cloth, clamps, seams, mats and mounting may need different allowances.
| Fabric and stitching | Stitched design (in) | Stitched design (cm) | Cut: +3 in each side (in) | Cut: +3 in each side (cm) | Whole-design hoop / Q-Snap opening |
|---|---|---|---|---|---|
| 11ct Aida | 12.73 × 18.18 in | 32.33 × 46.18 cm | 18.73 × 24.18 in | 47.57 × 61.42 cm | Hoop design diagonal ≈ 22.19 in; rectangular Q-Snap usable opening must contain the 12.73 × 18.18 in design. |
| 14ct Aida | 10.00 × 14.29 in | 25.40 × 36.29 cm | 16.00 × 20.29 in | 40.64 × 51.53 cm | Hoop design diagonal ≈ 17.44 in; rectangular Q-Snap usable opening must contain the 10.00 × 14.29 in design. |
| 16ct Aida | 8.75 × 12.50 in | 22.23 × 31.75 cm | 14.75 × 18.50 in | 37.47 × 46.99 cm | Hoop design diagonal ≈ 15.26 in; rectangular Q-Snap usable opening must contain the 8.75 × 12.50 in design. |
| 18ct Aida | 7.78 × 11.11 in | 19.76 × 28.22 cm | 13.78 × 17.11 in | 35.00 × 43.46 cm | Hoop design diagonal ≈ 13.56 in; rectangular Q-Snap usable opening must contain the 7.78 × 11.11 in design. |
| 25ct evenweave over 2 12.5 effective count | 11.20 × 16.00 in | 28.45 × 40.64 cm | 17.20 × 22.00 in | 43.69 × 55.88 cm | Hoop design diagonal ≈ 19.53 in; rectangular Q-Snap usable opening must contain the 11.20 × 16.00 in design. |
| 28ct linen over 2 14 effective count | 10.00 × 14.29 in | 25.40 × 36.29 cm | 16.00 × 20.29 in | 40.64 × 51.53 cm | Hoop design diagonal ≈ 17.44 in; rectangular Q-Snap usable opening must contain the 10.00 × 14.29 in design. |
| 32ct linen over 2 16 effective count | 8.75 × 12.50 in | 22.23 × 31.75 cm | 14.75 × 18.50 in | 37.47 × 46.99 cm | Hoop design diagonal ≈ 15.26 in; rectangular Q-Snap usable opening must contain the 8.75 × 12.50 in design. |
The hoop diagonal and rectangular opening checks reuse the existing hoop calculator. Values describe an opening enclosing the entire design at once, rounded for display; measure beyond the exact unrounded requirement. A smaller working hoop or frame can be moved. Q-Snap’s nominal outside size is not its usable opening, and this table does not certify clamp clearance or enough mounting cloth.
Worked example: 140 × 200 on 14ct Aida
- Use 14ct Aida over one: effective count = 14 ÷ 1 = 14 stitches per inch.
- Stitched width = 140 ÷ 14 = 10.00 inches; stitched height = 200 ÷ 14 = 14.29 inches.
- Add 3 inches on each side: width = 140 ÷ 14 + 6 and height = 200 ÷ 14 + 6, giving a nominal 16.00 × 20.29 inch cut.
- Multiply the unrounded inch dimensions by 2.54: the design is 25.40 × 36.29 cm and the nominal cut is 40.64 × 51.53 cm. Check actual fabric and finishing requirements before cutting.
Full crosses and estimated DMC skein equivalents
A completely filled 140 × 200 rectangle has 28000 full crosses. The second row assumes 70% coverage; it is an illustration, not a measured chart count.
| Coverage assumption | Full crosses | Estimated pooled skein equivalents | Continue with these inputs |
|---|---|---|---|
| 100% | 28000 | 15.74 | Open this 100% floss estimate → |
| 70% | 19600 | 11.02 | Open this 70% floss estimate → |
Both rows call the live calculator’s existing planning function: 14ct, two strands, standard mixed-pattern usage and the same skein-utilization assumptions. No new yield or waste coefficients are introduced. Pooled equivalents are not a per-color shopping list: estimate and round each color separately. Half stitches, backstitch, blending and rework can change usage. See the existing DMC stitches-per-skein model and limitations.
Continue with a related chart
Browse all ten choices in the fabric comparison and size-chart hub. For 200 × 200 stitches, use the existing 200x200 Aida comparison.
Questions about this size chart
Why is an 11 × 14 opening too short for the 14ct portrait?
Its stitched height is 14.29 inches before any border. The rectangular fit check fails in either orientation; compare a larger measured opening or another fabric count.
Does rotating the frame also change the chart’s width and height?
Rotation swaps the opening’s axes for the fit comparison. It does not reduce the stitched rectangle or preserve the intended upright subject automatically. Check the composition in its final orientation.
Which allowance belongs outside the visible portrait border?
Mounting or lacing cloth belongs beyond the display area. In the 18ct example, the 1.00 inch border and 3.00 inch finishing allowance are separate inputs; the resulting cut is 15.78 × 19.11 inches.
